ICOM ID-52A

The All New ID-52A is a Larger Radio, with a Larger Color Display, and Louder Audio.

The ID-52A is not a replacement for the ID-51A. To the contrary, it's much more! It’s a new way of communicating!

The new Transceiver represents an industry first, a handheld with a beautiful, full color waterfall display and the ability to send photos over the D-STAR network.

• Continue to support D-STAR functions
• DR Mode for easy access to local repeaters based on the internal GPS information
• Functions in Terminal and Access Point modes
• Weighing in at a mere 10.4oz (295g)
• Has an 80% increase in overall volume to hear in loud conditions

Specifications:

• Output Power: 5W / 2.5W / 1.0W / 0.55W / 0.1W

RX Frequencies:

• Wideband Receiver (88.0 – 174, 225 – 479*)
• VHF/UHF Airband and FM Broadcast Receiver
• * Guaranteed range: 144-148, 440-450 MHz

Channels: 1000

Bluetooth®: Built-in

Waterproof Rating: IPX7

GPS: Built-in

Other Exciting Features:

• Large Color Screen with Waterfall Functions
• The ID-52A houses a large 2.3" color screen with 320 x 280 pixels (1.7" for the ID-51A)
• Easily switch between black or white backgrounds
• Industry-first full-color waterfall display in a Handheld! (View the current band conditions to see if frequencies are open for use)
• Dualwatch allows for the monitoring of two frequencies or bands simultaneously. VHF/VHF, UHF/UHF and VHF/UHF monitoring are all supported along with the new ability to decode two DV signals simultaneously. Quickly call from either the main or sub bands on the fly
• Enhanced UHF capabilities allows for monitoring of Military Airbands from 225 to 374.995 MHz and the wideband receiver allows for listening to nearby broadcast FM stations

Bluetooth® Enabled Features:

• The ID-52A incorporates common Bluetooth® profiles for audio and data controls, which provide new mobility in the palm of your hand.
• Icom leads the way by pairing either Icom or third-party headsets for voice communications. Download the RS-MS1A Remote Control Software on Google Play to change operating frequencies, send texts, and more!
• The optional VS-3 Bluetooth® headset with the large PTT button allows for hands-free operation. Additionally, users can program 3 buttons to improve operability and mobility.

Integrated GPS/GLONASS Receiver:

• With a GPS lock, use the D-PRS mode to send location data, as well as show received station location, distance, and direction.
• The ID-52A also displays current Grid Square information
• This GPS position data can be used for the Position Auto Reply, Near Repeater Search and GPS log functions.

Even More Features:

• microSD Card Slot
• Micro USB Connector
• Improved Heat Dissipation Efficiency
• QSO Log in CSV Data Format
• Voice Recorder Function
