Key Features:
- Expanded Frequency Range: Provides reliable measurements for frequencies up to 230 MHz, ideal for HF and VHF bands.
- Advanced Charting Modes: Includes the Smith Chart.
- Advanced Table Modes: Multiband Mode to visualize and compare antenna performance across multiple bands. Multé – automatically evaluates all HAM bands in your region, assigning a 1-5 star rating to bands where SWR is below 3.0, for easy performance tracking. Quick Band Access – allows instant navigation to selected bands for faster measurements.
- Advanced Tools: Stub Tuner, Length vs VF, Cable Loss, Cable Impedance, and OSL Calibration simplify complex measurements.
- Advanced Features: SWR2Air capability, which transmits measured values via speaker or air using the same antenna, and enjoy Bluetooth connectivity for wireless data management.
Who Will Benefit:
- Ham Radio Operators – Optimize antennas with professional-grade tools for all key bands.
Antenna Designers – Gain precision and versatility when crafting or tuning antenna systems.
- Field Technicians – Streamline troubleshooting and fine-tuning of antennas and cables.
- Educators and Experimenters – Provide a deeper understanding of antenna behavior through advanced charting and measurement tools.
This license transforms your device into a robust, versatile analyzer, catering to users who demand high precision and comprehensive tools for their antenna projects.
SPECIFICATIONS:
Frequency Range:
Operation Modes:
- R, X chart
- Return loss chart
- Smith chart (Advanced, RFE licenses)
- SWR at single or multiple frequencies
- SWR chart
- SWR, return loss, R, X, Z, L, C at single frequency
Tools:
- cable loss and characteristic impedance measurement (Advanced, RFE licenses)
- Length & velocity factor (Advanced, RFE licenses)
- OSL calibration (Advanced, RFE licences)
- Self-test
- Stub tuner (Advanced, RFE licenses)
