ALINCO DR-135TMKIII

ALINCO DR-135TMKIII

2 Meter 50 Watt FM Transceiver with High Stability TCXO

Regular Price: $174.95

Additional Savings

-$10.00  2022 Holiday Sales Event (Exp:11/28/22)

HRO Discount Price: $164.95*

  Ham Radio Warranty  Ham Radio Warranty

*After Coupons & Promotions.

Current Stock Status At These Ham Radio Outlet Locations
DR-135TMKIII Description     Hide

Great News - HRO now provides an optional Extended Warranty on this item. For details see the warranty options in the accessory section below. HRO Extended warranties must be purchased at the same time the product is purchased or within 30 calendar days of the original product purchase date.

ALINCO's DR-135TMKIII is a very popular 144MHz VHF Mobile for Amateur Amateur Radio applications. The DR-135 delivers power and performance without compromising a higher price. Its User-Friendly configuration and programmable features make the DR-135 an ideal choice for Amateur Radio usage World-Wide

DR-135TMKIII FEATURES:

  • 50 watts, H/M/L power settings
  • 100 memory channels
  • Front panel data port
  • Rear panel D-SUB9 computer connection
  • No need to remove mic for packet operation
  • Ignition key on/off feature
  • CTCSS, DCS encode+decode, DTMF encode and Tone-burst are all standards
  • Clean, clear Alinco audio
  • Super-wide 7 character alphanumeric display
  • Wide and narrow FM modes (16K0 & 8K50F3E)
  • Theft alarm feature
  • A large, palm-fitting commercial-grade backlit microphone with a metal connector (not a modular plug) as well as direct frequency input and direct multi-function access such as monitor, call channel, power setting, memory to VFO plus more!
  • Stays in mode you select (voice/packet) through power off cycles
  • Ten autodial memories and more....at Low Alinco price!
SPECIFICATIONS:

Frequency range

TX(T): 144-147.995MHz (FM)
RX(T): 118-135.995 MHz (AM)
RX: 136-173.995MHz (FM)

Operating mode

16K0F3E (FM)/8K50F3E (Narrow-FM)
F1(9600bps)/F2(1200bps)/10F3 * 1
/A3E (RX only DR135TMkII)

Channel steps

5, 8.33, 10, 12.5, 15, 20, 25, 30, 50 KHz

Memory channel

100 channels + 1 quick recall (CALL)

Antenna impedance

50ohm unbalanced

Frequency stability

+/- 2.5ppm TCXO

Power supply requirement

13.8V DC +/- 15% negative ground

Current drain

Approx. 11.0A TX High
Approx. 0.4A squelched

Usable temperature range

14°C ~ 140°F (-10°C ~ +60°C)

Dimensions (w/o projection)

5.59"(W) x 1.57"(H) x 6.85"(D) in.
140(W) x 40(H) x 174(D) mm

Weight

Approx. 1.0Kg (35.3oz)

CTCSS tone

encoder/decoder 39 tones

Digital Coded Squelch

encoder/decoder 104 codes

TRANSMITTER:

Output power

Approx. 50W(HI)
Approx. 20W(MID)
Approx. 5W(LOW)

Modulation system

Variable reactance frequency modulation

Spurious emission

Less than -60 dB

Maximum frequency deviation

+/- 5 KHz (FM) / +/- 2.5 KHz (NFM)

RECEIVER:

Receive system

Double-conversion superheterodyne

Sensitivity (-12dB SINAD)

Less than -16.0dBu

Intermediate frequency

1st IF 21.7 MHz, 2nd IF 450 KHz

Selectivity

-6dB: +/-12KHz or more (FM)
-60dB: +/-28KHz or less
-6dB: +/-6KHz or more (NFM)
-60dB: +/-16KHz or less

Audio output power

More than 2W(8ohm 10%THD)

Note:

* 1 Optional units required
* 2 Typical within the amateur radio band(s).

STANDARD ACCESSORIES:
  • Instruction Manual.
  • EMS-57 DTMF Microphone
  • Mounting Bracket w/Screws
  • DC Power Cable
  • Microphone holder
  • Alarm cable
OPTIONAL ACCESSORIES:
  • EMS-53 Plain Non-DTMF Microphone
  • EMS-14 Desktop Microphone
  • EJ-47U Digital Voice unit module
  • ERW-7 or ERW-15 USB Programming cable
  • Alinco Power Supply DM-330/30T/430T
  • RT Systems (APK-DR03) Programming software pack
    Manufacturer's Website
    Product Website
