Frequency: 1.8-200 MHz
Power Range Forward: 20/200/2000 Watts
Accuracy: +/- 10% (at full scale)
SWR Detection Sensitivity: 5 Watts min
Input/Output Impedence: 50 Ohms
Input/Output Connectors: SO-239
Dimensions & Weight: 6.25 x 4.3 x 4.8 / 2 lbs. 3 oz.
Lighted
SWR and Power indicators are indicated all in one meter unit. SWR will be indicated at the crossing point of the 2 needles. This unique feature makes it possible to read all of Forward Power, Reflected Power and SWR at the same time.
HP type can also measure P.E.P. Peak Power in SSB operation. (can not measure Reflected Power range.)
