HF-6M/2M/440MHz Triplexer
This table explains the frequency range, insertion loss and also max power handling capabilities of the Comet CFX-514N Triplexer
| Frequency Range |
Loss |
Max Power |
| 1.3-90MHz |
0.2dB |
800w PEP |
| 130-200MHz |
0.25dB |
800w PEP |
| 380-500MHz |
0.3dB |
500w PEP |
Isolation: 55dB
CONNECTORS:
Common: SO-239
Low In: PL-259 with coax lead
Mid Pass: PL-259 with coax lead
High Pass: N-Male with coax lead
