YAESU FTDX-10
YAESU-FTDX-10-Image-1 YAESU-FTDX-10-Image-2 YAESU-FTDX-10-Image-1

YAESU FTDX-10

HF/50MHz 100W SDR Amateur Radio Transceiver

Regular Price: $1,699.95

Additional Savings

-$120.00  Yaesu Mfr Coupon (Exp:01/31/25)
-$200.00  HRO Holiday Savings! (Exp:01/31/25)

HRO Discount Price: $1,379.95*



*After Coupons & Promotions.

Current Stock Status At These Ham Radio Outlet Locations
FTDX-10 Description     Hide


Ranked #3 On Sherwood Engineerings List Of Top Performing Receivers


Hybrid SDR Configuration:

The new FTDX10 utilizes Yaesus Renowned Hybrid SDR configuration just like the FTDX101 Series.

The Narrow band SDR receiver emphasizes excellent receiver performance, while the Direct Sampling SDR provides a Digital Processing Real-Time Spectrum Scope.

Main Features:

  • Narrow Band SDR with 3 types of Roofing Filters
  • Phenomenal Multi-signal receiving Characteristics

The receiver uses a Down Conversion Configuration with the first IF at 9MHz affording the receiver the ability to incorporate excellent narrow bandwidth crystal roofing filters that have the desired sharp “cliff edge” shape factor.

  • 250MHz High Resolution Direct Digital Synthesizer affords Quiet and Clear Reception
  • 3DSS (3-Dimensional Spectrum Stream) on the 5-inch Full-Color TFT Display with Touch-Panel Functionality
  • Front Panel Designed for Superior Operating Efficiency
  • Remote Operation with optional LAN unit (SCU-LAN10)


The features of the New FTDX10 include:

  • 15 separate band pass filters
  • Effective QRM rejection with the IF DSP (IF SHIFT/WIDTH, IF NOTCH DNF, DNR, COUNTOUR)
  • High-quality and super stable final amplifier utilizing the new push-pull MOSFET RD70HUP2
  • Aluminum Heat Sink with 80mm low-noise axial flow cooling fan
  • High Speed Automatic Antenna Tuner with a large capacity 100-channel memory
  • RF & AF Transmit Monitor
  • Microphone Amplifier with Three-stage parametric Equalizer (SSB/ AM mode)
  • QMB (Quick Memory Bank)
  • Band Stack Function
  • Optional speaker – SP-30 designed for the new FTDX10
  • Optional roofing filter (300Hz) – XF-130CN available


Radio Features:

  • HF/50MHz band 100W Transceiver
  • Hybrid SDR configuration utilizing a Narrow Bandwidth SDR and a Direct Sampling SDR
  • Narrow Band SDR enables Phenomenal Multi-signal Receiving characteristics (2kHz RMDR 116dB+, 2kHz BDR 141dB+, 2kHz 3rd IMDR 109dB+)
  • Down conversion, 9MHz IF Roofing Filters produce Excellent Shape Factor
  • 250 MHz HRDDS (High Resolution Direct Digital Synthesizer) Ultra Low-Noise Local-Oscillator System
  • 15 Separate Powerful Band Pass Filters (BPF)
  • Effective QRM Rejection with IF DSP (IF SHIFT/WIDTH, IF NOTCH/DNF,CONTOUR,DNR, APF)
  • High-quality and Super-Stable Final Amplifier utilizing the new push-pull MOSFET RD70HUP2
  • 5-inch Full Color Touch Panel and 3DSS (3-Dimensional Spectrum Stream) Display
  • MPVD (Multi-Purpose VFO Outer Dial) enables Outstanding Operating Performance
  • Quick Memory Bank (QMB)
  • Supports CW operation with multiple functions such as: CW zero-in, CW Auto zero-in, CW Reverse, CW decode, CW keying Signal form Shaping by FPGA and others
  • RTTY (FSK)/ PSK Encode/Decode Function
  • Other practical features such as Optional RF Gain Selection by IPO. Automatic Gain Control, Quick Split Function
  • SD Card Slot
  • Remote Operation via Internet with optional LAN-Unit (SCU-LAN10)


Specifications:

Frequency Ranges:

  • RX 30kHz - 75MHz (Operating)
  • RX 1.8MHz - 29.699999MHz (Specified performance, Amateur bands only)*
  • RX *5.1675/5.332/5.348/5.3585/5.373/5.405MHz (US only), 5.351500-5.366500MHz (EU only)/ 5.25000-5.406500 (UK only)
  • RX 50MHz - 53.999999MHz (Specified performance, Amateur bands only)
  • RX 70MHz - 70.499999MHz (Specifed performance, UK Amateur bands version only)
  • TX 1.8 - 54MHz (Amateur bands only)


Modulation Type: A1A(CW), A3E(AM), J3E(LSB,USB), F3E(FM),F1B(RTTY),G1B(PSK)

Frequency Stability: ±0.5ppm (32°F to +122°F/0? to +50?, after 1min)

Supply Voltage: DC 13.8V ±15%

Circuit Type: Double-Conversion Superheterodyne

Intermediate Frequencies:

  • 1st IF 9.005MHz
  • 2nd IF 24kHz


RF Power Output:

  • 5W - 100W (CW, LSB, USB, FM, RTTY, PKT)
  • 5W -25W (AM)


Case Size(W x H x D):
10.47 x 3.58 x 10.35(inch) / 266 x 91 x 263 (mm) *Protruding parts not included

Weight (Approx.): 13lbs/ 5.9kg


Supplied Accessories:

  • Microphone SSM-75E
  • DC Power Cable w/Fuse
  • Spare Fuse
  • 6.3mm 3-contact Plug
  • Operating Manual
