Navigator Sound Card Modem
The Navigator is a complete USB sound card modem featuring a proven USB audio sound card chip, six FTDI USB serial COM ports, a K1EL WinKey keyer, True FSK and rig control connections for every radio. It has a built-in USB sound card with isolated audio I/O to your radio to prevent ground loops. A second audio input lets you use both receivers in a dual receiver radio. The logic level and RS-232 rig control ports support your Icom CI-V, Yaesu CAT, Kenwood and other radios. Front panel controls set both RX audio levels, TX audio ouput level, audio monitor level and the CW speed. There are no internal configuration jumpers - just conveniently set the software-controlled configuration settings from your PC.
* Mac users will need to contact Timewave directly to confirm Mac device compatibility.
Single USB connection to computer
- USB Sound Card built-in
- USB Powered
- Universal Rig Control built-in - logic level +/-, CI-V, CAT, & RS-232!
- Software Configuration - No jumpers!
- FSK Controller for Precision RTTY
- K1EL Paddle & Keyboard Precision CW
- Separate COM ports for PTT, FSK, CW, CI-V & RS-232
