Note: The radio must be connected to a 13.8v power supply in order to update the firmware.
-------------------------------------------------------------------
FIrmware Update | CLICK HERE to Download.
-------------------------------------------------------------------
The G90 is an advanced portable 20W HF 10-160 Meter Multimode SDR Transceiver. The G90 uses 24 bit digital architecture. It also includes an internal automatic antenna tuner. The G90 has excellent transmit and receive performance. It packs huge performance into a small portable package. The G90 has a removable display head that can be separated from the main body and connected via a DB-9 cable (provided with the radio). Both the radio's control head firmware and main body operating firmware can be user-updated using separate connectors on the head and body. The programming cable is provided.
G90 Main Features:
- Detachable Display Unit: The detachable display design allows you to customize your installation.
- Color LCD Display Shows: ±24khz bandwidth spectrum and waterfall. The sweep/refresh rate is very fast. The status of all functions are shown on the LCD display.
- Convenient Side Interface: The G90 uses a standard 3.5mm stereo jack (3-pin) for connecting headphones. Also on the control head is a Firmware update port.
- Multi-Function Mic: The microphone has two configurable and several dedicated function buttons.
Specifications:
- Modes: SSB / CW / AM / FM *
- RF Output Power: 20W (SSB/CW/FM), 5W (AM Carrier), 13.8VDC, stepping 0.5W
- Receive frequency range: 0.5 MHz-30 MHz
- Operating voltage range: 10.5-16.5 V DC (voltage must be in 13.8-15V if need 20W)
- Talking range: Max 4000km+, min 500-600km (affected by topography)
- Transmission frequency: All amateur bands in the range of 1.8 to 29.999 MHz plus 60 meters in USA
- Receive current draw: 500mA
- Transmit current draw: 8A max.
- Operating temperature range: -10 C ~ +50 C
- Frequency stability: ± 10 ppm after warm-up
- Size of the machine: 4.75" x 1.75" x 8.25" (main body without handles)
- Machine weight: Around 1 kg
- Antenna Socket: SO-239, Impedance 50 Ω
Package Content:
- 1 x Xiegu G90 Transceiver
- 1 x Multi-function Microphone
- 1 x Firmware Cable
- 1 x Power Cable
- 1 x DB-9 Remote head cable
- 1 x Operation Manual
- 1 x Warranty Card
- 1 x Certificate
- 2 x Fixed Stud
- 1 x Hexagon Screwdriver
- 4 x Front and rear extension handles
